PRODUCT FEATURES
● Compliant with QSFP28 Standard: SFF-8636 Rev 2.10a
● Compliant with IEEE802.3cu D3.2 100GBASE-LR1
● High speed I/O electrical interface (CAUI-4)
● Single 3.3V Supply Voltage
● Maximum power consumption 4.5W
● 0-70 ºC Case Operating Temperature
● 1311nm EML laser and PIN Receiver
● Hermetically sealed TO Based design
● QSFP28 MSA package with duplex LC connector
● Two Wire Serial Interface with Digital Diagnostic Monitoring
● KP4 FEC termination inside module
● Supporting 10km reach of single mode fiber
● Complies with EU Directive 2011/65/EU (RoHS compliant)
● Class 1 Laser
APPLICATIONS
● 100GBASE-LR
